ABB AC500 PLC - Intended Purpose; Functionality; Electrical Connection

9 Label
10 Terminal unit
11 DIN rail
Sign for XC version
Intended Purpose
The device can be used as a decentralized I/O extension module for S500 Communication
Interface Modules (e. g. CI592-CS31, CI501-PNIO, CI541-DP, CI581-CN) or as a centralized
extension module for AC500 CPUs (PM5xx).
Functionality
● 16 digital inputs 24 VDC
● 8 configurable digital inputs/outputs 24 VDC, 0.5 A max.
● 4 analog inputs, voltage, current and RTD.
Resolution 12 bits plus sign
● 2 analog outputs, voltage and current
Resolution 12 bits plus sign
● Fast counter
Parameter Value
Fast Counter Integrated, many configurable operating
modes
Power supply From the process supply voltage UP
LED displays For system displays, signal states, errors and
power supply
Internal supply voltage Via the expansion bus interface (I/O bus)
External supply voltage Via terminals UP and ZP (process supply
voltage 24 VDC)
Effect of incorrect input terminal connection Wrong or no signal detected, no damage up to
35 V
Required terminal unit
TU515 or TU516 Ä Chapter 1.4.3 “TU515,
TU516, TU516-H and TU542 for I/O Modules”
on page 153
Electrical Connection
For a detailed description of the mounting, disassembly and electrical connec-
tion of the module, please refer to the System Assembly, Construction and Con-
nection chapter Ä Chapter 2.6 “AC500 (Standard)” on page 1248.
The electrical connection is carried out by using the 40 terminals of the terminal unit TU515/
TU516
Ä Chapter 1.4.3 “TU515, TU516, TU516-H and TU542 for I/O Modules” on page 153.
The assignment of the terminals:
Device Specifications
I/O Modules > Digital/Analog I/O Modules
2019/04/173ADR010121, 13, en_US570
