ABB AC500 PLC User Manual

Range Digital value
Decimal Hex.
Normal range 27648
:
1
6C00
:
0001
0 0000
-1
:
-27648
FFFF
:
9400
Measured value too low -1
:
-4864
FFFF
:
ED00
-27649
:
-32512
93FF
:
8100
Underflow -32768 8000
Resistance Thermometer Input Ranges
Range Pt100
-50 ... +70 °C
1
)
Pt100 /
Pt1000
-50 ... +400
°C
Pt100
-200 ... +850
°C
Ni1000
-50 ... +150
°C
Cu50
-200 ... +200
°C
Overflow > 80.0 °C > 450.0 °C > 850 °C > 160.0 °C > 200 °C
Measured
value too high
450.0 °C
:
400.1 °C
160.0 °C
:
150.1 °C
80.0 °C
:
70.1 °C
Normal range :
:
:
:
70.0 °C
:
0.1 °C
:
400.0 °C
:
:
:
:
0.1 °C
850.0 °C
:
:
:
:
:
0.1 °C
:
:
:
150.0 °C
:
:
0.1 °C
:
:
200.0 °C
:
:
:
0.1 °C
0.0 °C 0.0 °C 0.0 °C 0.0 °C
Device Specifications
I/O Modules > Analog I/O Modules
2019/04/173ADR010121, 13, en_US498

ABB AC500 PLC Specifications

General

Digital Inputs	Up to 1024
Digital Outputs	Up to 1024
Real-time clock	Yes
Power Supply	24 V DC
Protection Class	IP20
Processor	ARM based
Programming Languages	IEC 61131-3 (LD, ST, FBD, SFC, IL)
Operating Temperature	-25°C to +70°C
Communication Interfaces	Ethernet, CAN, RS-232, RS-485
