ABB AC500 PLC - Temperature-Internal Reference Point Ranges

Range Typ J
-210 ... +1200
°C
Typ K
-270 ... +1372
°C
Typ N
-270 ... +1300
°C
Typ S
-50 ... +1768
°C
Typ T
-270 ... +400
°C
: 1300.0 °C :
1200.0 °C : : :
: : : : 400.0 °C
: : : : :
0.1 °C 0.1 °C 0.1 °C 0.1 °C 0.1 °C
0.0 °C 0.0 °C 0.0 °C 0.0 °C
-0.1 °C -0.1 °C -0.1 °C -0.1 °C -0.1 °C
: : : : :
: : : -50.0 °C :
-210.0 °C : : : :
-270.0 °C -270.0 °C -270.0 °C
Underflow < -210.0 °C < -270.0 °C < -270.0 °C < -50.0 °C < -270.0 °C
The represented resolution corresponds to 16 bits.
Range Digital value
Decimal Hex.
Overflow 32767 7FFF
Normal range 17680 4510
13720 3598
13000 32C8
12000 2EE0
4000 0FA0
: :
1 1
0 0000
-1 FFFF
: :
-500 FE0C
-2100 F7CC
-2700 F574
Underflow -32768 8000
Temperature-Internal Reference Point Ranges
Range Value
Overflow > +85 °C
Normal range +85 °C
0 °C
