ABB AC500 PLC - 1.8.2.8 TK502 - Programming Cable

CTS Clear To Send
DCD Data Carrier Detect
DTR Data Terminal Ready
DSR Data Set Ready
FE Functional Earth
RI Ring Indicator
RTS Request To Send
RxD Receive Data
SGND Signal Ground
TxD Transmit Data
The TK501 cable connects a 9-pole serial COM interface of a PC with the serial COM2 interface
of PM57x, PM58x and PM59x. It is used for programming purposes.
With AC500/AC500-eCo processor modules, only the ABB programming cables
TK50x can be used. Other cables may cause communication faults and must
not be used.
The 2 plugs are put on the 2 COM interfaces and tightened there.
Parameter Value
Connector at the PC (COM interface) D-sub, 9-pole, female
Connector at the Processor Module (COM2) D-sub, 9-pole, male
Cable length 5 m
Cable type LiYCY 5 x 0.14 mm², shielded
Weight 220 g
Part No. Description Product Life Cycle Phase *)
1SAP 180 200 R0001 TK501, programming cable
D-sub / D-sub, length: 5 m
Classic
*) For planning and commissioning of new installations use modules in Active
status only.
1.8.2.8 TK502 - Programming Cable
● Cablel on PC side: D-sub, 9-pole, female, RS-232, for COM interface
● Cable on AC500 side: terminal block, 9-pole, female, RS-232, for COM1 interface
● Cable length: 5 m
Purpose
Electrical Con-
nection
Technical Data
Ordering Data
