1.7.4.2.4 Internal Data Exchange
Digital inputs (bytes) 5
Digital outputs (bytes) 5
Counter input data (words) 4
Counter output data (words) 8
1.7.4.2.5 Addressing
The IP address of the CI5221-MODTCP Module can be set with the
“ABB IP Configuration Tool”.
If the last byte of the IP is set to 0, the address switch will be used instead.
Address switch position 255 is mapped to fixed IP 192.168.0.254 independent of other stored
settings. This is a backup so the module can always get a valid IP address and can be config-
ured by the “ABB IP Configuration Tool”.
Address switch position 0 is mapped to last byte equal 1 and DHCP enabled.
The factory setting for the IP is 192.168.0.x (last byte is address switch).
The module reads the position of the rotary switches only during power-up, i. e.
changes of the switch position during operation will have no effect until the next
module initialization.
1.7.4.2.6 I/O Configuration
The CI522-MODTCP stores configuration parameters (IP address configuration, module param-
eters).
The digital I/O channels are configured via software.
Details about configuration are described in Parameterization
Ä
Chapter 1.7.4.2.7 “Parameteri-
zation” on page 926.
1.7.4.2.7 Parameterization
Parameters of the Module
Name Value Internal value Internal value,
type
Default
Module ID
1
)
Internal 7405 WORD 7405
Ignore Module Internal 0 BYTE 0
Parameter length Internal 47 BYTE 47
Error LED / Fail-
safe function
(Table Error
LED / Failsafe
function
Ä
Table 150 “
Table Error LED /
Failsafe function”
on page 928)
On 0 BYTE 0
Off by E4 1
Off by E3 3
On + failsafe 16
Off by E4 + fail-
safe
17
Off by E3 + fail-
safe
19
Communication Interface Modules (S500) > Modbus
2019/04/173ADR010121, 13, en_US926
