ABB AC500 PLC - 1.6.1.1.9 Ordering Data

Parameter Value
Frequency accuracy
From 10 Hz to 500 Hz ± 2 %
From 501 Hz to 250 kHz ± 1 %
Differential output voltage (at terminal block) 2.8 V at 140 W differential
load
2.56 V at 100 W differen-
tial load
Output voltage of positive output (P0+, P1+) referenced to SGND if
used for single ended application
Max. 3.3 V without any
load
Typ. 2.5 V at 100 W load
Max. short circuit current 40 mA
Max. cable length
Shielded 300 m (at max. fre-
quency, criterion: V
≥ 2 V, tested with 100 W
termination)
Unshielded 30 m
1.6.1.1.9 Ordering Data
Part No. Description Product Life Cycle Phase *)
1SAP 233 100 R0001 FM562, pulse-train output module,
2 axes, RS-422, 4 DI, 24 VDC
Active
1TNE 968 901 R3101 Terminal block TA563-9, 9 pins, screw
front, cable side, 6 pieces per unit
Active
1TNE 968 901 R3102 Terminal block TA563-11, 11 pins,
screw front, cable side, 6 pieces per
unit
Active
1TNE 968 901 R3103 Terminal block TA564-9, 9 pins, screw
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3104 Terminal block TA564-11, 11 pins,
screw front, cable front, 6 pieces per
unit
Active
1TNE 968 901 R3105 Terminal block TA565-9, 9 pins, spring
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3106 Terminal block TA565-11, 11 pins,
spring front, cable front, 6 pieces per
unit
Active
*) For planning and commissioning of new installations use modules in Active
status only.
Device Specifications
Function Modules > S500-eCo
2019/04/17 3ADR010121, 13, en_US 651
