ABB AC500 PLC - Ordering Data; 1.5.1.1.5 DI571 - Digital Input Module

Parameter Value
Input voltage +30 V < 8 mA
Max. permissible leakage current (at 2-
wire proximity switches)
1 mA
Input delay (0->1 or 1->0) Typ. 8 ms
Input data length 2 bytes
Max. cable length
Shielded 500 m
Unshielded 300 m
Ordering Data
Part No. Description Product Life Cycle Phase *)
1TNE 968 902 R2102 DI562, digital input module, 16 DI,
24 VDC
Active
1TNE 968 901 R3101 Terminal block TA563-9, 9 pins, screw
front, cable side, 6 pieces per unit
Active
1TNE 968 901 R3102 Terminal block TA563-11, 11 pins,
screw front, cable side, 6 pieces per
unit
Active
1TNE 968 901 R3103 Terminal block TA564-9, 9 pins, screw
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3104 Terminal block TA564-11, 11 pins,
screw front, cable front, 6 pieces per
unit
Active
1TNE 968 901 R3105 Terminal block TA565-9, 9 pins, spring
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3106 Terminal block TA565-11, 11 pins,
spring front, cable front, 6 pieces per
unit
Active
*) For planning and commissioning of new installations use modules in Active
status only.
1.5.1.1.5 DI571 - Digital Input Module
● 8 digital inputs 100-240 VAC (I0 to I7) in 8 groups
● Module-wise electrically isolated
Device Specifications
I/O Modules > Digital I/O Modules
