Parameter Value
Influence of line-conducted interferences Yes, according to:
IEC 61000-4-6, zone B,
criterion A
Influence of power frequency magnetic fields Yes, according to:
IEC 61000-4-8, zone B,
criterion A
In order to prevent malfunctions, it is recommended, that the operating per-
sonnel discharge themselves prior to touching communication connectors or
perform other suitable measures to reduce effects of electrostatic discharges.
NOTICE!
Risk of malfunctions!
Unused slots for communication modules are not protected against accidental
physical contact.
– Unused slots for communication modules must be covered with dummy
communication modules (TA524
Ä
Chapter 2.6.5.4 “TA524 - Dummy Com-
munication Module” on page 1304 to achieve IP20 rating.
– I/O bus connectors must not be touched during operation.
2.7.1.2 Mechanical Data
Parameter Value
Wiring method Spring terminals
Degree of protection IP 20
Vibration resistance Yes, according to:
IEC 61131-2
IEC 60068-2-6
IEC 60068-2-64
Shock resistance Yes, according to:
IEC 60068-2-27
Assembly position Horizontal
Vertical (no application in salt mist environ-
ment)
Assembly on DIN rail
DIN rail type According to IEC 60715
35 mm, depth 7.5 mm or 15 mm
Assembly with screws
Screw diameter 4 mm
Fastening torque 1.2 Nm
System Assembly, Construction and Connection
AC500-XC > System Data AC500-XC
2019/04/173ADR010121, 13, en_US1312
