Table 8: Accessories
Part No. Description
1TNE 968 901
R3101
Terminal Block TA563-9, 9-pin, screw front, cable side, 6 pieces per
unit
1TNE 968 901
R3102
Terminal Block TA563-11, 11-pin, screw front, cable side, 6 pieces per
unit
1TNE 968 901
R3103
Terminal Block TA564-9, 9-pin, screw front, cable front, 6 pieces per
unit
1TNE 968 901
R3104
Terminal Block TA564-11, 11-pin, screw front, cable front, 6 pieces per
unit
1TNE 968 901
R3105
Terminal Block TA565-9, 9-pin, spring front, cable front, 6 pieces per
unit
1TNE 968 901
R3106
Terminal Block TA565-11, 11-pin, spring front, cable front, 6 pieces per
unit
1SAP 180 100
R0001
MC502: Memory card
1TNE 968 901
R0100
MC503: Memory card adaptor for PM55x-xP and PM56x-xP
1TNE 968 901
R1100
TK503: programming cable USB ³ RS485 SUB-D
1TNE 968 901
R2100
TK504: programming cable USB ³ RS485 terminal block
1TNE 968 901
R3200
TA561-RTC: real-time clock adaptor for PM55x-xP and PM56x-xP
1TNE 968 901
R4300
TA562-RS: RS-485 adaptor for PM55x-xP and PM56x-xP
1SAP 186 400
R0001
TA569-RS-ISO: RS-485 adaptor with galvanic isolation for PM55x-XP
and PM56x-xP
1TNE 968 901
R5210
TA562-RS-RTC: real-time clock and RS-485 adaptor for PM55x-xP and
PM56x-xP
1TNE 968 901
R3107
TA566: wall mounting accessory, 100 pieces
1TNE 968 901
R3203
TA570: spare part set for AC500-eCo processor modules
1.2.1.2 Onboard I/Os in Processor Module PM55x
● 8 DI 24 VDC
● PM55x-T(P): 6 DO (24 VDC, 0.5 A max. transistor outputs)
● PM55x-R(P) and PM55x-R(P)-AC: 6 DO (24 VDC or 120/240 VAC, 2 A max. relay outputs)
Device Specifications
