1.3.5.1.4 Technical Data
The System Data of AC500 and S500 Ä Chapter 2.6.1 “System Data AC500” on page 1248 are
valid for standard version.
The System Data of AC500-XC
Ä Chapter 2.7.1 “System Data AC500-XC” on page 1309 are
valid for the XC version.
Only additional details are therefore documented below.
Parameter Value
Internal Supply Via the communication module interface of the
terminal base
Protocol EtherCAT
Field bus connector 2 x RJ45 (ETHCAT1 and ETHCAT2)
Technology Hilscher netX100
Transfer rate 10/100 Mbit/s (full-duplex)
Transfer method According to Ethernet II, IEE802.3
Ethernet 100 base-TX, internal switch, 2x RJ45 socket
Bus length (segment length max.) 100 m at 100 Mbit/s
Indicators 5 LEDs
Usable CPUs
PM57x, PM58x, PM59x Ä Chapter 1.2.2.1
“PM57x (-y), PM58x (-y) and PM59x (-y)”
on page 65
PM56xx
Usable terminal bases
All TB5xx Ä Chapter 1.1.1 “TB51x-TB54x”
on page 4
All TB56xx (not TB5600)
Ambient temperature
System data AC500 Ä Chapter 2.6.1 “System
Data AC500” on page 1248
System Data AC500 XC
Ä Chapter 2.7.1
“System Data AC500-XC” on page 1309
Current consumption from 24 VDC power
supply at the terminal base of the CPU
Typ. 85 mA
Internal supply Via the communication module interface of the
terminal base
Number of slaves Limited to 200
Quantity of input and output data for a single
slave
Max. 5760 byte (respectively for input and
output)
Total quantity of input and output data Max. 5760 byte (respectively for input and
output)
Supported protocols RTC - Real-time cyclic protocol, class 1
RTA - Real-time acyclic protocol
Acyclic services ● CoE upload
● CoE download (1500 bytes max.)
● Emergency
Min. bus cycle 1 ms
Max. size of the bus configuration file 2 MB
Weight Ca. 170 g
Device Specifications
Communication Modules (AC500 Standard) > EtherCAT
2019/04/17 3ADR010121, 13, en_US 119
