Power
AX522
I/O Terminal Unit TU515/TU516
ZP
supply
DIN
rail
I/O-Bus
UP CH-ERRx
0V
UP
+24V
I+ I–
I/O-Bus
Analog I/O interface
Inputs Outputs
+ – + –
I+ I– O+ O–
+ – + –
O+ O–
PTC PTC
1 M
1 M
2.4.4 EMC-Conforming Assembly and Construction
2.4.4.1 General Principles
Electric and electronical devices have to work correctly on site. This is also valid when electro-
magnetic influences affect them in defined and/or expected strength. The devices themselves
must not emit electro-magnetic noises.
Advant Controller components have a very high noise immunity.
When the wiring and earthing instructions are met, an error-free operation is given.
High electro-magnetic noises of nearby mounted applications must be taken in consideration
during the planning phase.
An EMC compatible earthing concept will also guarantee an error-free operation here.
Block Diagram:
Analog I/O Mod-
ules
General Consid-
erations
System Assembly, Construction and Connection
Overall Information (valid for complete AC500 Product Family) > EMC-Conforming Assembly and Construction
2019/04/173ADR010121, 13, en_US1186
