Parameter Value
Output resistance (load),
as current output
0 ... 500 W
Output loadability,
as voltage output
± 10 mA max.
Indication of the output signals 1 LED per channel (brightness depends on the
value of the analog signal)
Resolution 12 bits (+ sign)
Conversion error of the analog values
caused by non-linearity, adjustment error at
factory and resolution within the normal
range
Typ. 0.5 %, max. 1 %
Relationship between input signal and hex
code
Table Output Ranges Voltage and Current
Ä
Chapter 1.7.3.1.10.3 “Output Ranges
Voltage and Current” on page 853
Unused outputs Are configured as unused (default value) and
can be left open-circuited
1.7.3.1.12 Ordering Data
Part No. Description Product Life Cycle Phase *)
1SAP 220 900 R0001 CI511-ETHCAT, EtherCAT bus
module, 8 DI, 8 DO, 4 AI and 2 AO
Active
*) For planning and commissioning of new installations use modules in Active
status only.
1.7.3.2 CI512-ETHCAT
● 8 digital inputs 24 VDC
● 8 digital outputs 24 VDC, 0.5 A max.
● 8 configurable digital inputs/outputs 24 VDC, 0.5 A max.
● Cam switch functionality (see also Extended Cam Switch Library)
● Extended Cam switch functionality *)
(see also Extended Cam Switch Library)
● Module-wise electrically isolated
● Expandability with up to 10 S500 I/O modules *)
*) Applicable for device index C0 and above.
Communication Interface Modules (S500) > EtherCAT
2019/04/17 3ADR010121, 13, en_US 859
