NOTICE!
Risk of corrosion!
Unused connectors and slots may corrode if XC devices are used in salt-mist
environments.
Protect unused connectors and slots with TA535 protective caps for XC devices
TA535
Ä
Chapter 1.8.4.6 “TA535 - Protective Caps for XC Devices”
on page 1172.
1.4.2.1 Technical Data
The System Data of AC500 and S500
Ä
Chapter 2.6.1 “System Data AC500” on page 1248 are
valid for standard version.
The System Data of AC500-XC
Ä
Chapter 2.7.1 “System Data AC500-XC” on page 1309 are
valid for the XC version.
Only additional details are therefore documented below.
Parameter Value
Number of I/O channels per module Max. 24 (depending on the inserted bus
module)
Distribution of the channels into groups 3 groups of max. 8 channels each (2.0...2.7,
3.0...3.7, 4.0...4.7), the allocation of the chan-
nels is given by the inserted bus module
Network interface connector 9-pin D-sub connector, female
Rated voltage 24 VDC
Max. permitted total current 10 A via the supply terminals (UP, UP3 and
ZP)
Earthing Direct connection to the earthed DIN rail or via
the screws with wall mounting
Screw terminals Front terminal, conductor connection vertically
with respect to the printed circuit board
Spring terminals Front terminal, conductor connection vertically
with respect to the printed circuit board
Weight 200 g
Mounting position Horizontal or vertical
1.4.2.2 Ordering Data
Part No. Description Product Life Cycle Phase *)
1SAP 211 000 R0001 TU509, terminal unit, 24 VDC, screw
terminals
Active
1SAP 210 800 R0001 TU510, terminal unit, 24 VDC, spring
terminals
Active
1SAP 410 800 R0001 TU510-XC, terminal unit, 24 VDC,
spring terminals, XC version
Active
Terminal Units (AC500 Standard) > TU509 and TU510 for Communication Interface Modules
2019/04/173ADR010121, 13, en_US152
