Parameter Value
Indication of the output signals 1 LED per channel (brightness depends on
the value of the analog signal)
Resolution 12 bits (+ sign)
Conversion error of the analog values caused
by non-linearity, adjustment error at factory
and resolution within the normal range
Typ. 0.5 %, max. 1 %
Relationship between input signal and hex
code
Ä
Chapter 1.5.3.1.2.9.3 “Output Ranges
Voltage and Current” on page 627
Unused outputs Are configured as "unused" (default value)
and can be left open-circuited
Ordering Data
Part No. Description Product Life Cycle Phase *)
1SAP 250 800 R0001 DA502, digital/analog input/output
module, 16 DO, 8 DC, 4 AI, 2 AO
Active
1SAP 450 800 R0001 DA502-XC, digital/analog input/output
module, 16 DO, 8 DC, 4 AI, 2 AO,
XC version
Active
*) For planning and commissioning of new installations use modules in Active
status only.
1.6 Function Modules
1.6.1 S500-eCo
1.6.1.1 FM562 for Pulse Train Output
● 2 axes motion control
● 2 pulse train outputs per axis, RS-422
● 2 configurable digital inputs per axis, 24 VDC
● 32 bits registers for current position, registered position and speed value
● Group-wise electrically isolated
Function Modules > S500-eCo
2019/04/173ADR010121, 13, en_US634
