Thermocouple Type Range Accuracy
S -50 °C...+150 °C
+150 °C...+1768 °C
±1.5 %
±0.6 %
T -270 °C...-240 °C
-240 °C...-0 °C
0 °C...+400 °C
±3 %
±2 %
±0.6 %
These accuracy values are valid only for stable module temperatures.
Ordering Data
Part No. Description Product Life Cycle Phase *)
1TNE 968 902 R1103 AI563, analog input module, 4 AI,
thermocouple
Active
1TNE 968 901 R3101 Terminal block TA563-9, 9 pins, screw
front, cable side, 6 pieces per unit
Active
1TNE 968 901 R3102 Terminal block TA563-11, 11 pins,
screw front, cable side, 6 pieces per
unit
Active
1TNE 968 901 R3103 Terminal block TA564-9, 9 pins, screw
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3104 Terminal block TA564-11, 11 pins,
screw front, cable front, 6 pieces per
unit
Active
1TNE 968 901 R3105 Terminal block TA565-9, 9 pins, spring
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3106 Terminal block TA565-11, 11 pins,
spring front, cable front, 6 pieces per
unit
Active
*) For planning and commissioning of new installations use modules in Active
status only.
1.5.2.1.4 AO561 - Analog Output Module
● 2 configurable analog outputs (O0 and O1) in 1 group
● Resolution: 11 bits plus sign or 12 bit
Device Specifications
I/O Modules > Analog I/O Modules
