ABB AC500 PLC - Channel Parameters for the Analog Inputs (4 x)

Channel Parameters for the Analog Inputs (4x)
Name Value Internal value Internal value,
type
Default
Input 0, Channel
configuration
Table Operating
modes of the
analog inputs
Ä Table 167 “Ch
annel Configura-
tion”
on page 1027
Table Operating
modes of the
analog inputs
Ä Table 167 “Ch
annel Configura-
tion”
on page 1027
BYTE 0
Input 0, Check
channel
Table Channel
montoring
Ä Table 168 “Ch
annel Monitoring”
on page 1028
Table Channel
montoring
Ä Table 168 “Ch
annel Monitoring”
on page 1028
BYTE 0
: : : : :
: : : : :
Input 3, Channel
configuration
Table Operating
modes of the
analog inputs
Ä Table 167 “Ch
annel Configura-
tion”
on page 1027
Table Operating
modes of the
analog inputs
Ä Table 167 “Ch
annel Configura-
tion”
on page 1027
BYTE 0
Input 3, Check
channel
Table Channel
montoring
Ä Table 168 “Ch
annel Monitoring”
on page 1028
Table Channel
montoring
Ä Table 168 “Ch
annel Monitoring”
on page 1028
BYTE 0
Table 167: Channel Configuration
Internal value Operating modes of the analog inputs, individually configurable
0 (default) Not used
1 0 V...10 V
2 Digital input
3 0 mA...20 mA
4 4 mA...20 mA
5 -10 V...+10 V
8 2-wire Pt100 -50 °C...+400 °C
9 3-wire Pt100 -50 °C...+400 °C *)
10 0 V...10 V (voltage diff.) *)
11 -10 V...+10 V (voltage diff.) *)
14 2-wire Pt100 -50 °C...+70 °C
15 3-wire Pt100 -50 °C...+70 °C *)
16 2-wire Pt1000 -50 °C...+400 °C
17 3-wire Pt1000 -50 °C...+400 °C *)
18 2-wire Ni1000 -50 °C...+150 °C
Device Specifications
Communication Interface Modules (S500) > PROFINET
2019/04/17 3ADR010121, 13, en_US 1027
