ABB AC500 PLC - Parameterization

Hence, replacing I/O modules is possible without any re-parameterization via software.
If the external power supply voltage via UP/ZP terminals fails, the I/O module
loses its configuration data. The whole station has to be switched off and on
again to re-configure the module.
Parameterization
The arrangement of the parameter data is performed with Automation Builder software.
The parameter data directly influences the functionality of modules.
For non-standard applications, it is necessary to adapt the parameters to your system configu-
ration.
Param-
eter
name
Value Internal
value
Data type
of
internal
value
Default
value
Min. Max. EDS Slot
Index
Module ID Internal
6160
1
)
WORD 6160
0x1810
0 65535
xx01
2
)
Ignore
module
No 0 BYTE No
0x00
- - -
Yes 1
Parameter
length
Internal 3 BYTE 3 0 255
xx02
2
)
Input
delay
20 ms 0 BYTE 20 ms
0x00
0 1 -
100 ms 1
1
) With CS31 and addresses less than 70, the value is increased by 1.
2
) Value is hexadecimal: HighByte is slot (xx: 0...7), LowByte is index (1...n).
GSD file:
Ext_Module_Prm_Data_Len = 7
Ext_User_Prm_Data_Const(0) = 0x18, 0x11, 0x00, 0x03, 0x00, 0x00, 0x00;
Device Specifications
I/O Modules > Digital I/O Modules
2019/04/17 3ADR010121, 13, en_US 219
