2.7.1.3 Environmental Tests
Parameter Value
Storage IEC 60068-2-1 Test Ab: cold withstand test -40 °C / 16 h
IEC 60068-2-2 Test Bb: dry heat withstand test +85 °C / 16 h
Humidity IEC 60068-2-30 Test Db: Cyclic (12 h / 12 h) damp-heat test
55 °C, 93 % r. H. / 25 °C, 95 % r. H., 6 cycles
IEC 60068-2-78, stationary humidity test: 40 °C, 93 % r. H.,
240 h
Insulation Test IEC 61131-2
Vibration resistance IEC 61131-2 / IEC 60068-26: 5 Hz...500 Hz, 2 g (with SD
memory card inserted)
IEC 60068-2-64: 5 Hz...500 Hz, 4 g rms
Shock resistance IEC 60068-2-27: all 3 axes 15 g, 11 ms, half-sinusoidal
Table 226: EMC Immunity
Parameter Value
Electrostatic discharge (ESD) Electrostatic voltage in case of air discharge: 8 kV
Electrostatic voltage in case of contact discharge: 6 kV
Fast transient interference vol-
tages (burst)
Supply voltage units (DC): 4 kV
Digital inputs/outputs (24 VDC): 2 kV
Analog inputs/outputs: 2 kV
Communication lines shielded: 2 kV
I/O supply (DC-out): 2 kV
High energy transient interference
voltages (surge)
Supply voltage units (DC): 1 kV CM *) / 0.5 kV DM *)
Digital inputs/outputs (24 VDC): 1 kV CM *) / 0.5 kV DM *)
Digital inputs/outputs (AC): 4 kV
Analog inputs/outputs: 1 kV CM *) / 0.5 kV DM *)
Communication lines shielded: 1 kV CM )*
I/O supply (DC-out): 0,5 kV CM *) / 0.5 kV DM *)
Influence of radiated disturbances Test field strength: 10 V/m
Influence of line-conducted inter-
ferences
Test voltage: 10 V
Power frequency magnetic fields 30 A/m 50 Hz
30 A/m 60 Hz
*) CM = Common Mode, * DM = Differential Mode
