The I/O module must not be used as a decentralized I/O module with CI590-
CS31-HA bus modules.
Functionality
Parameter Value
LED displays For signal states
Internal power supply Via I/O bus
External power supply Via the terminals ZP and UP (process voltage 24 VDC)
Electrical Connection
For a detailed description of the mounting, disassembly and electrical connec-
tion of the module, please refer to the System Assembly chapter
Ä
Chapter 2.5
“AC500-eCo” on page 1192.
The electrical connection is carried out by using removable 9-pin and 11-pin terminal blocks.
These terminal blocks differ in their connection system (spring terminals or screw terminals,
cable mounting from the front or from the side). For more information, please refer to the
chapter Terminal Blocks for S500-eCo I/O Modules
Ä
Chapter 1.8.3.2 “TA563-TA565 - Terminal
Blocks” on page 1164. The terminal blocks are not included in the module's scope of delivery and
must be ordered separately.
The following block diagram shows the internal construction of the digital inputs and outputs:
I/O Modules > Digital I/O Modules
2019/04/173ADR010121, 13, en_US274
