ABB AC500 PLC - Ordering Data; 1.5.1.1.7 DO561 - Digital Output Module

Parameter Value
Max. permissible leakage current (at 2-wire prox-
imity switches)
1 mA
Max. cable length
Shielded 1000 m
Unshielded 600 m
Ordering Data
Part No. Description Product Life Cycle Phase *)
1SAP 230 500 R0000 DI572, digital input module, 16 DI,
100 VAC...240 VAC
Active
1TNE 968 901 R3101 Terminal block TA563-9, 9 pins, screw
front, cable side, 6 pieces per unit
Active
1TNE 968 901 R3102 Terminal block TA563-11, 11 pins,
screw front, cable side, 6 pieces per
unit
Active
1TNE 968 901 R3103 Terminal block TA564-9, 9 pins, screw
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3104 Terminal block TA564-11, 11 pins,
screw front, cable front, 6 pieces per
unit
Active
1TNE 968 901 R3105 Terminal block TA565-9, 9 pins, spring
front, cable front, 6 pieces per unit
Active
1TNE 968 901 R3106 Terminal block TA565-11, 11 pins,
spring front, cable front, 6 pieces per
unit
Active
*) For planning and commissioning of new installations use modules in Active
status only.
