1.7.2.2.8 Parameterization
Parameters of the Module - if used with Fast Counter
Name Value Internal value Internal value,
type
Default
Module ID
1
)
Internal 2725 WORD 2725
Parameter length Internal 22 BYTE 22
Error LED / Fail-
safe function
2
)
On 0 BYTE 0
Off by E4 1
Off by E3 3
On + failsafe 16
Off by E4 + fail-
safe
17
Off by E3 + fail-
safe
19
Check supply off 0 BYTE
on 1 1
If the bus module is configured as a Fast Counter module and '0 - no Counter'
in Automation Builder is selected the channel ERR LEDs stays on and the
module does not start up. The address was adjusted with '71'.
Only the '0- no Counter' mode does not operate. If any other counter is selected
e.g. '1-1 Up counter' the module starts up and can be utilized.
Parameters of the Module - if used without Fast Counter
Name Value Internal value Internal value,
type
Default
Module ID
1
)
Internal 2726 WORD 2726
Parameter length Internal 23 BYTE 23
Error LED / Fail-
safe function
2
)
On 0 BYTE 0
Off by E4 1
Off by E3 3
On + failsafe 16
Off by E4 + fail-
safe
17
Off by E3 + fail-
safe
19
Check supply Off 0 BYTE
On 1 1
Remarks:
1
) With a faulty Module ID, the Modules reports a "parameter error" and does not perform cyclic
process data transmission
2
) Error LED/Failsafe function:
