Parameter Value
Output load ability as voltage output +2 mA max.
Accuracy for current and voltage output
Typical (25 °C) ±1 % of full-scale
Worst case (at 0 °C...60 °C or EMC distur-
bances)
±2.5 % of full-scale
Relationship between input signal and hex
code
Ä
Chapter 1.2.1.3.10 “Output Ranges”
on page 59
Unused inputs Can be left open and should be configured
as "unused"
Overvoltage protection Yes, up to 30 VDC
Max. cable length Conductor cross section > 0.14 mm²
Unshielded wire On request
Shielded wire 100 m
1.2.2 AC500 (Standard)
1.2.2.1 PM57x (-y), PM58x (-y) and PM59x (-y)
Processor modules without onboard interfaces:
● PM57x, PM58x, PM59x: processor module without Ethernet support
● The processor module PM595 is described in a seperate device description
Ä
Chapter
1.2.2.2 “PM595” on page 80
● XC version for usage in extreme ambient conditions available (some models versions only)
Processor modules with onboard interfaces:
● PM5xy-ETH: processor module with Ethernet support (onboard Ethernet) - 1 network inter-
face RJ45 on the terminal base
● PM5xy-2ETH: processor module with Ethernet support (onboard Ethernet) - 2 network inter-
faces RJ45 on the terminal base
● PM5xy-ARC: processor module with ARCNET support (onboard ARCNET) - 1 network
interface ARCNET BNC on the terminal base
Processor Modules > AC500 (Standard)
2019/04/17 3ADR010121, 13, en_US 65
