ABB AC500 PLC - 1.1.2.3 Technical Data

See supported protocols and used Ethernet ports for AC500 V3 prod-
ucts:Ethernet Protocols and Ports.
See communication via Modbus for AC500 V3 products: Modbus TCP/IP.
See communication via Modbus for AC500 V3 products: Modbus RTU.
NOTICE!
Risk of corrosion!
Unused connectors and slots may corrode if XC devices are used in salt-mist
environments.
Protect unused connectors and slots with TA535 protective caps for XC devices
TA535 Ä Chapter 1.8.4.6 “TA535 - Protective Caps for XC Devices”
on page 1172.
1.1.2.3 Technical Data
The System Data of AC500 and S500
Ä Chapter 2.6.1 “System Data AC500” on page 1248 are
valid for standard version.
The System Data of AC500-XC Ä Chapter 2.7.1 “System Data AC500-XC” on page 1309 are
valid for the XC version.
Only additional details are therefore documented below.
Parameter Value
Connection of the supply voltage 24
VDC at the TF5x1-CMS
The terminals 1.8, 4.8...7.8, 1.9, 4.9...7.9, 4.0...4.7,
7.0...7.7 are electrically interconnected within the
TF5x1-CMS.
Terminals 1.8, 4.8...7.8: process voltage L+ = +24 VDC
Terminals 1.9, 4.9...7.9: process voltage M = 0 V
Terminals 4.0...4.7, 7.0...7.7: analog shield clamps SH
Terminal 1.0: FE shield clamp of encoder
Rated voltage 24 VDC
Max. permitted total current 10 A (between terminals 1.8, 4.8...7.8 and 1.9,
4.9...7.9)
Slots
TF501-CMS 1 function module FM502-CMS, 1 processor module
PM592-ETH, 0 communication modules
TF521-CMS 1 function module FM502-CMS, 1 processor module
PM592-ETH, 2 communication modules
Processor module interfaces I/O bus, COM1
Weight TF501-CMS: 350 g
TF521-CMS: 400 g
Mounting position Horizontal or vertical
Device Specifications
