1.3.6.1.4 Technical Data
The System Data of AC500 and S500
Ä
Chapter 2.6.1 “System Data AC500” on page 1248 are
valid for standard version.
The System Data of AC500-XC
Ä
Chapter 2.7.1 “System Data AC500-XC” on page 1309 are
valid for the XC version.
Only additional details are therefore documented below.
Parameter Value
Field bus 2 x Ethernet
Transmission rate 10 Mbit/s or 100 Mbit/s
Protocol Ethernet TCP/IP, UDP/IP, Modbus TCP, ICMP
(Ping), DNS, SMTP (email)
Field bus connectors 2 x RJ45, with integrated 2-port switch
Processor Hilscher netX100
Usable CPUs
PM57x, PM58x, PM59x
Ä
Chapter 1.2.2.1
“PM57x (-y), PM58x (-y) and PM59x (-y)”
on page 65
Usable terminal bases
All TB5xx
Ä
Chapter 1.1.1 “TB51x-TB54x”
on page 4
Communication module interface Dual-port memory, 16 kByte
Current consumption from 24 VDC power
supply at the terminal base of the CPU
Typ. 85 mA
Internal power supply Via the communication module interface of the
terminal base
External RAM memory 8 MByte
External flash memory 8 MByte
State display PWR, RDY, RUN, STA, ERR, 2 x LINK, 2 x
ACT
Ethernet 10/100 Base-TX, internal switch, 2 x RJ45
socket
LED indication State indication via 5 LEDs
Station identification Rotary switch, 0...255 (00...FFhex)
Transmission mode Half or full-duplex operation, adjustable
Transmission rate 10 or 100 Mbit/s, adjustable
Auto negotiation Optionally adjustable
MAC address Optionally configurable
Ethernet frame types Ethernet II (RFC 894), IEEE 802.3 receive
only (RFC 1042)
Weight Ca. 170 g
Communication Modules (AC500 Standard) > Ethernet
2019/04/17 3ADR010121, 13, en_US 123
