Input/Output Characteristics of CI502-PNIO
● 8 digital inputs 24 V DC
● 8 digital transistor outputs 24 V DC, 0.5 A max.
● 8 configurable digital inputs/outputs 24 V DC, 0.5 A max.
● Module-wise electrically isolated
● XC version for usage in extreme ambient conditions available
Technical Data of the Serial Interfaces of CI504-PNIO
Parameter Value
Number of serial interfaces 3
Connectors for serial interfaces X11 for COM1
X12 for COM2
X13 for COM3
Supported physical layers RS-232
RS-422
RS-485
Supported protocols ASCII
Baudrate Configurable from 300 bit/s to 115.200 bit/s
Technical Data of the Serial Interfaces of CI506-PNIO
Parameter Value
Number of serial interfaces 2
Connectors for serial interfaces X11 for COM1
X12 for COM2
Supported physical layers RS-232
RS-422
RS-485
Supported protocols ASCII
Baudrate Configurable from 300 bit/s to 115.200 bit/s
Technical Data of the CANopen Interfaces (CI506-PNIO)
Parameter Value
Number of CANopen interfaces 1
Connector for CANopen Interface X13
Baudrate Up to 1 Mbit/s
1.7.6.2 CI501-PNIO
● 4 analog inputs, 2 analog outputs, 8 digital inputs, 8 digital outputs
● Resolution 12 bits plus sign
Device Specifications
