ABB AC500 PLC - Current Input Ranges

Range Digital value
Decimal Hex.
Normal range 27648
:
1
6C00
:
0001
0 0000
Measured value too low -1
:
-4864
FFFF
:
ED00
Underflow -32768 8000
Current Input Ranges
Range -20 ... +20 mA 0 ... +20 mA 4 ... 20 mA
Overflow > 23.5178 > 23.5178 > 22.8142
Measured value too
high
23.5178
:
20.0007
23.5178
:
20.0007
22.8142
:
20.0006
Normal range 20.0000
:
0.0007
20.0000
:
0.0007
20.0000
:
4.0006
0.0000 0.0000 4.0000
-0.0007
:
-20.0000
Measured value too
low
-0.0007
:
-3.5178
3.9994
:
1.1852
-20.0007
:
-23.5178
Underflow < -23.5178 < -3.5178 < 1.1852
Range Digital value
Decimal Hex.
Overflow 32767 7FFF
Measured value too high 32511
:
27649
7EFF
:
6C01
Device Specifications
I/O Modules > Analog I/O Modules
2019/04/17 3ADR010121, 13, en_US 497
