Diagnosis Table CI590-CS31-HA
In case of overload or short circuit, the outputs switch off automatically and try to switch on
again cyclically. Therefore an acknowledgement of the outputs is not necessary. The LED error
message, however, is stored.
E1...E4 d1 d2 d3 d4 Identi-
fier
000...06
3
AC500 display <− Display in
Class Comp Dev Mod Ch Err PS501 PLC
browser
Byte 6
Bit 6...7
- Byte 3 Byte 4 Byte 5 Byte 6
Bit 0...5
FBP diagnosis
block
Class Inter-
face
Devic
e
Module Chann
el
Error
identi-
fier
Error message Remedy
1
)
2
)
3
)
4
)
Module Error
3 11 ADR 31 31 3 Timeout in the I/O
module
Replace I/O
module
3 11 ADR 31 31 19 Checksum error in
the I/O module
3 11 ADR 31 31 36 Internal data
exchange failure
3 11 ADR 31 31 40 Different hard-/firm-
ware versions in the
module
3 11 ADR 31 31 43 Internal error in the
module
3 11 ADR 31 31 9 Overflow diagnosis
buffer
Restart
3 11 ADR 31 31 26 Parameter error Check master
3 11 ADR 31 31 11 Process voltage too
low
Check process
voltage
3 11 ADR 1...7 31 17 No communication
to the I/O module
Replace I/O
module
3 11 ADR 31 31
31
28 Configurations from
PLC A of PLC B are
different
Check PLC
CS31 module
configuration
3 11 ADR
ADR
31 31 36 Wait Com (Only 1
bus or 1 CPU is
active/operational)
Check second
CPU or other
bus connection
4 11 ADR 31 31 45 Process voltage
ON/OFF
Process voltage
ON
4 11 ADR 31/
1...7
31 34 Wait ready (No
reply during initiali-
zation of the I/O
module)
Replace I/O
module
4 11 ADR 31/
1...7
31 32 Wrong I/O module
in the slot
Replace I/O
module or check
configuration
