Parameter Value
Counting frequency Depending on operation mode:
Mode 1 - 6: max. 200 kHz
Mode 7: max. 50 kHz
Mode 9: max. 35 kHz
Mode 10: max. 20 kHz
Detailed description See Fast Counter
Operating modes See Operating modes
1.7.5.1.12 Ordering Data
Ordering No. Scope of delivery Product Life Cycle Phase *)
1SAP 224 100 R0001 CI541-DP, PROFIBUS DP bus
module, 8 DI, 8 DO, 4 AI and 2 AO
Active
1SAP 424 100 R0001 CI541-DP-XC, PROFIBUS DP bus
module, 8 DI, 8 DO, 4 AI and 2 AO,
XC version
Active
*) For planning and commissioning of new installations use modules in Active
status only.
1.7.5.2 CI542-DP
● 8 digital inputs 24 VDC
● 8 digital outputs 24 VDC, 0.5 A max.
● 8 configurable digital inputs/outputs 24 VDC, 0.5 A max.
● Module-wise electrically isolated
● Fast counter
● XC version for usage in extreme ambient conditions available
Device Specifications
Communication Interface Modules (S500) > PROFIBUS
