In AC500, the following interface identifier applies: 14 = I/O bus, 11 = COM1 (e.g.
CS31 bus), 12 = COM2. The FBP diagnosis block does not contain this identifier.
2
)
With "Device" the following allocation applies: 31 = module itself, 1..10 = decen-
tralized communication interface module 1..10, ADR = hardware address (e.g. of
the DC551)
3
)
With "Module" the following allocation applies depending on the master: Module
error: I/O bus or FBP: 31 = module itself; COM1/COM2: 1..10 = expansion 1..10
channel error: I/O bus or FBP = module type (1 = AI); COM1/COM2: 1..10 =
expansion 1..10
4
)
In case of module errors, with channel "31 = Module itself" is output.
1.6.2.2.4 State LEDs
During the power-on procedure, the module initializes automatically. All LEDs (except the LEDs
for the signal states) are on during the initialization.
LED State Color LED = ON LED = OFF LED flashing
AI0 - AI15 Analog
channel state
Green Channel acti-
vated and OK
Channel
deactivated
CMS meas-
urement run-
ning
Red Short circuit
(only in IEPE
mode) over- /
undervoltage
(only in +-10V
mode)
- Cable break
(only in IEPE
mode)
A, B, Z Encoder 0
inputs
Yellow Input ON Input OFF LED follows
the state of
the inputs,
depending on
frequency
DI0, DI1,
DC2, DC3
Digital inputs Yellow Input = ON
(the input
voltage is
even dis-
played if the
supply voltage
is OFF).
Input = OFF -
DC2, DC3 Digital outputs Yellow Output = ON Output OFF -
5 V Power supply
for encoders
Green Configuration
ON and power
5-V-power
ready
Configuration
OFF or power
failure
Power supply
outputs are
short-circuited
L+ Process
supply voltage
Green Process
voltage OK
Initialization
finished
Process
voltage OFF
Firmware
update
CH-ERR1,
CH-ERR2
Red Serious error
within the cor-
responding
group
No error or
process
voltage is
missing
Error on one
channel of the
corresponding
group (e.g.
short circuit at
an output)
2019/04/173ADR010121, 13, en_US690
