ABB AC500 PLC - Group Parameters for the Analog Part

1
)
With a faulty ID, the modules reports a "parameter error" and does not perform
cyclic process data transmission.
2
)
As for device index C0 the parameter is no longer evaluated.
3
)
Counter operating modes, see description of the Fast counter Ä Chapter
1.5.1.2.10 “Fast Counter” on page 394.
Table 166: Error LED / Failsafe function
Setting Description
On Error LED (S-ERR) lights up at errors of all
error classes, Failsafe-mode off
Off by E4 Error LED (S-ERR) lights up at errors of error
classes E1, E2 and E3, Failsafe-mode off
Off by E3 Error LED (S-ERR) lights up at errors of error
classes E1 and E2, Failsafe-mode off
On +Failsafe Error LED (S-ERR) lights up at errors of all
error classes, Failsafe-mode on *)
Off by E4 + Failsafe Error LED (S-ERR) lights up at errors of error
classes E1, E2 and E3, Failsafe-mode on *)
Off by E3 + Failsafe Error LED (S-ERR) lights up at errors of error
classes E1 and E2, Failsafe-mode on *)
*) The parameters Behaviour AO at comm. error and Behaviour DO at comm. error are only
analyzed if the Failsafe-mode is ON.
Group Parameters for the Analog Part
Name Value Internal value Internal value,
type
Default
Analog data
format
Standard
Reserved
0
255
BYTE 0
Behaviour AO at
comm. error *)
Off
Last value
Last value 5 s
Last value 10 s
Substitute value
Substitute value
5 s
Substitute value
10 s
0
1
6
11
2
7
12
BYTE 0
*) The parameter Behaviour AO at comm. error is only analyzed if the Failsafe-mode is ON.
Device Specifications
Communication Interface Modules (S500) > PROFINET
2019/04/173ADR010121, 13, en_US1026
