To avoid a short battery discharge, the battery should always be inserted or
replaced while the process module is under power, then the battery is correctly
recognized and will not shortly discharged.
Parameter Value
Nominal voltage 3 V
Nominal capacity 560 mAh
Temperature range (index below C0) Operating: 0 °C...+60 °C
Storage: -20 °C...+60 °C
Transport: -20 °C...+60 °C
Temperature range (index C0 and above) Operating: -40 °C...+70 °C
Storage: -40 °C...+85 °C
Transport: -40 °C...+85 °C
Battery lifetime Typ. 3 years at 25 °C
Self-discharge 2 % per year at 25 °C
5 % per year at 40 °C
20 % per year at 60 °C
Protection against reverse polarity Yes, by mechanical coding of the plug.
Insulation The battery is completely insulated.
Connection Red = plus pole = above at plug, black =
minus pole,
Weight 7 g
Dimensions Diameter of the button cell: 24.5 mm
Thickness of the button cell: 5 mm
Part No. Description Product Life Cycle Phase *)
1SAP 180 300 R0001 TA521, lithium battery Active
*) For planning and commissioning of new installations use modules in Active
status only.
Technical Data
Ordering Data
System Assembly, Construction and Connection
AC500 (Standard) > Handling of Accessories
2019/04/17 3ADR010121, 13, en_US 1295
