NOTICE!
Risk of damaging the PLC modules!
Overvoltages and short circuits might damage the PLC modules.
– Make sure that all voltage sources (supply and process voltage) are
switched off before you begin with operations at the system.
– Never connect any voltages or signals to reserved terminals (marked with
---). Reserved terminals may carry internal voltages.
The following block diagram shows the internal construction of the digital outputs:
I/O Modules > Digital I/O Modules
2019/04/173ADR010121, 13, en_US364
