Internal
value
Operating modes for the analog inputs, individually configurable
52 Temperature-internal reference point
53 Common mode voltage
Table 61: Channel Monitoring
Internal
value
Monitoring
0 Plausibility, open-circuit (cut wire) and short circuit (default)
3 No monitoring
Table 62: Line Frequency Suppression
Internal
value
Line frequency suppression
0 50 Hz
1 60 Hz
2 No line frequency suppression
Table 63: Compensation Channel
Internal
value
Compensation channel
0 Internal compensation (default)
1 Channel 0 (possible with channels 1, 2, 3)
2 Channel 1 (possible with channels 0, 2, 3)
3 Channel 2 (possible with channels 0, 1, 3)
4 Channel 3 (possible with channels 0, 1, 2)
5 Channel 4 (possible with channels 5, 6, 7)
6 Channel 5 (possible with channels 4, 6, 7)
7 Channel 6 (possible with channels 4, 5, 7)
8 Channel 7 (possible with channels 4, 5, 6)
9 External with temperature value
Device Specifications
I/O Modules > Analog I/O Modules
2019/04/173ADR010121, 13, en_US492
