19.9 24 V Auxiliary Supply (X1)

Thefollowingdiagram describes external 24 Vdc powersupply, electrically isolated, forexample, viaanisolating

transformer. Therequiredcurrent ratingdepends ontheuseof motorbrakeandoptioncard (see page1 orfollowing).

Pin Signal Description

1 +24 +24 Vdc Auxiliary voltage

2 GND 24V Supply GND

3 STO STO enable (Safe Torque Off)

AKD User Guide | Connection Diagrams

Kollmorgen | December 2010 233
