Kollmorgen AKD series User Manual

IL.IFOLD
General Information
Type R/O Parameter
Description Reads the overall foldback current limit.
Units A
Range 0 to 2,147,483.647 A
Default Value N/A
Data Type Float
See Also Foldback
Start Version M_01-00-00-000
Fieldbus Index/Subindex Object Start Version
EtherCAT COE and
CANopen
3425h/0 M_01-00-00-000
Modbus 444 M_01-03-00-000
Description
Two current foldback algorithms run in parallel in the drive: the drive foldback algorithm and the motor foldback
algorithm. Each algorithm uses different sets of parameters.
Each algorithm has its own foldback current limit, IL.DIFOLD and IL.MIFOLD. The overall foldback current limit
is the minimum of the two at any given moment.
IL.IFOLD = min (IL.DIFOLD, IL.MIFOLD).
IL.DIFOLD is an artificial current, which can be higher or lower than the drive or motor peak current. When
IL.IFOLD becomes lower than the existing current limit (such as IL.LIMITP), it becomes the active current limit.
Related Topics
11.3 Current Loop
AKD User Guide | IL Parameters
Kollmorgen | December 2010 469

Kollmorgen AKD series Specifications

General

Continuous Current	Up to 180 A
Control Modes	Position, Velocity, Torque
Communication Interfaces	EtherCAT, CANopen, Modbus TCP/IP
Feedback Options	Resolver, Encoder
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1)
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overtemperature
Switching Frequency	8 kHz, 16 kHz
Ambient Temperature	0°C to 40°C
Operating Temperature	0 - 40 °C (derating may apply)
Humidity	5% to 95% non-condensing
