Kollmorgen AKD series

REC.TRIGPARAM
General Information
Type R/W Parameter
Description Sets the parameter that triggers the recorder.
Units N/A
Range N/A
Default Value IL.FB
Data Type String
See Also REC.TRIG
Start Version M_01-00-00-000
Description
REC.TRIGPARAM sets the parameter on which the recorder triggers.
This parameter is only used when REC.TRIGTYPE = 2.
Input values are:
1. One of the set drive parameters list that can be set as a trigger. The available parameters for trigger are:
PL.ERR, PL.CMD, PL.FB, VL.CMD, VL.FB, IL.CMD, and IL.FB.
2. Internal value or variable of the drive (same as for DRV.MEMADDR input).
Related Topics
15 Scope
