Kollmorgen AKD series User Manual

7.2.4 Selecting a Compatible Regen Resistor
After you calculate the appropriate resistor size, compare the results with the capabilities of the drive and, if nec-
essary, select an external regeneration resistor which matches these capabilities from the chart below. The
resistors shown below are included in the WorkBench setup. If you do not find a match for your application,
please contact the Kollmorgen customer support team for further assistance.
NA Part
Number
EU Part
Number
Resistor Type AKD-
x-
00306
AKD-
x-
00606
AKD-
x-
01206
AKD-
x-
02406
AKD-
x-
00307
AKD-
x-
00607
AKD-
x-
01207
AKD-
x-
02407
BAFP-100-33 DE-201437 External Resistor,
100 W, 33 ohms
x x x
BAFP-200-33 DE-201438 External Resistor,
200 W, 33 ohms
x x x
BAR-250-33 DE-106254 External Resistor,
250 W, 33 ohms
x x x x x x
BAR-500-33 DE-106255 External Resistor,
500 W, 33 ohms
x x x x x x
BAR-1500-33 DE-106258 External Resistor,
1500 W, 33 ohms
x x x x x x
BAS-3000-33 DE-201407 External Resistor,
3000 W, 33 ohms
x x x x x x
BAR-600-23 DE-200613 External Resistor,
600 W, 23 ohms
x
BAR-1000-23 DE-200614 External Resistor,
1000 W, 23 ohms
x
BAS-2000-23 DE-200615 External Resistor,
2000 W, 23 ohms
x
BAS-3000-23 DE-200616 External Resistor,
3000 W, 23 ohms
x
BAS-4000-23 DE-200617 External Resistor,
4000 W, 23 ohms
x
BAR-500-15 DE-201439 External Resistor,
500 W, 15 ohms
x
BAR-1000-15 DE-201440 External Resistor,
1000 W, 15 ohms
x
BAS-2000-15 DE-103871 External Resistor,
2000 W, 15 ohms
x
BAS-3000-15 DE-103872 External Resistor,
3000 W, 15 ohms
x
BAS-6000-15 DE-103873 External Resistor,
6000 W, 15 ohms
x
7.2.5 Configuring Regen Parameter Values
If you use an external regen resistor, then you must also include additional information about the regen resistor in
thePowerview. These values are automatically inserted in WorkBench. The chart below summarizes these
three additional values:
l External Regen Resistance (REGEN.REXT, ohms)
l External Regen Heat Up Time (REGEN.TEXT, seconds)
l External Regen Power (REGEN.WATTEXT, watts)
Theseparameters allow the regenresistor tofunction properly and dissipate power appropriately for yoursystem.
AKD User Guide | 7 Configuring Drive Power
Kollmorgen | December 2010 57

Kollmorgen AKD series Specifications

General

Continuous Current	Up to 180 A
Control Modes	Position, Velocity, Torque
Communication Interfaces	EtherCAT, CANopen, Modbus TCP/IP
Feedback Options	Resolver, Encoder
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1)
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short Circuit, Overtemperature
Switching Frequency	8 kHz, 16 kHz
Ambient Temperature	0°C to 40°C
Operating Temperature	0 - 40 °C (derating may apply)
Humidity	5% to 95% non-condensing
