Kollmorgen AKD series User Manual

AKD User Guide | SM Parameters
SM.V2
General Information
Type R/W Parameter
Description
Sets service motion velocity 2; active in opmode 1 (velocity) and 2 (posi-
tion).
Units
Depends on UNIT.ACCROTARY or UNIT.ACCLINEAR
Rotary: rpm, rps, deg/s, (PIN/POUT)/s, rad/s
Linear: counts/s, mm/s, µm/s, (PIN/POUT)/s
Range
Rotary:
-12,000.000 to 12,000.000 rpm
-200.000 to 200.000 rps
-72,000.000 to 72,000.000 deg/s
-1,000.000 to 1,000.000 (PIN/POUT)/s
-1,256.637 to 1,256.637 rad/s
Linear:
-0.200 to 0.200 counts/s
-200.000*MOTOR.PITCH to 200.000*MOTOR.PITCH mm/s
-200,000.000*MOTOR.PITCH to 200,000.000*MOTOR.PITCH µm/s
-1,000.000 to 1,000.000 (PIN/POUT)/s
Default Value
Rotary:
-60.000 rpm
-1.000 rps
-359.999 deg/s
-5.000 (PIN/POUT)/s
-6.283 rad/s
Linear:
-0.001 counts/s
-1.000*MOTOR.PITCH mm/s
-999.998*MOTOR.PITCH µm/sec
-5.000 (PIN/POUT)/s
Data Type Float
See Also SM.I1, SM.I2, SM.MODE, SM.MOVE, SM.T1, SM.T2, SM.V1
Start Version M_01-00-00-000
Fieldbus Index/Subindex Object Start Version
Modbus 760 M_01-03-00-000
Description
SM.V2 defines the velocity that is used in service motion mode 1 (see SM.MODE) in the closed velocity and posi-
tion mode of operation.
Related Topics
12.3 Service Motion
598 Kollmorgen | December 2010
