Kollmorgen AKD series

AKD User Guide | PLS Parameters and Commands
PLS.EN
General Information
Type R/W Parameter
Description Enables programmable limit switch (PLS).
Units N/A
Range 0 to 255
Default Value 0
Data Type Integer
See Also
PLS.MODE, PLS.RESET, PLS.STATE, PLS.UNITS, PLS.P1 to
PLS.P8, PLS.WIDTH1 to PLS.WIDTH8, PLS.T1 to PLS.T8
Start Version M_01-02-03-000
Fieldbus Index/Subindex Object Start Version
EtherCAT COE
and CANopen
34A3h/1 M_01-02-03-000
Modbus 618 M_01-03-00-000
Description
PLS.EN is a bit variable which determines the mode of an individual PLS. Eight PLSs are available in the
drive.
Example
Bit Value Behavior
Bit 0 = 0 Disables PLS 1
Bit 0 = 1 Enables PLS 1
Bit 7 = 0 Disables PLS 8
Bit 7 = 1 Enables PLS 8
Related Topics
10.8 Programmable Limit Switch
554 Kollmorgen | December 2010
