UNIT.LABEL
General Information
Type NV Parameter
Description Sets user-defined name for user-defined position units.
Units N/A
Range Maximum 16 characters, no spaces
Default Value PIN/POUT
Data Type String
See Also UNIT.PLINEAR, UNIT.POUT
Start Version M_01-00-00-000
Description
If you define a special position unit with UNIT.PLINEAR and UNIT.POUT, then you can give this unit a descrip-
tive name. You can name the unit anything you wish, as long as the name is limited to 16 characters and
includes no spaces. This name is shown in derived units as velocity and acceleration.
This parameter is descriptive only and does not influence drive internal functions in any way.
Related Topics
9 Selecting Units for Your Application
