Parameter Value
Max. load for the terminals 10 A
Protection against reversed voltage Yes
Rated protection fuse on UP 10 A fast
Inrush current from UP (at power up) On request
Current consumption via UP (normal
operation)
0.15 A
Connections Terminals 1.0, 2.0 and 3.0 for +24 V (UP)
Terminals 1.1, 2.1 and 3.1 for 0 V (ZP)
Input data length 0...36 bytes
Output data length 0...36 bytes
Max. power dissipation within the module 5 W
Setting of the I/O device identifier With 2 rotary switches at the front side of the
module
Operation and error displays 18 LEDs (total)
Weight (without terminal unit) ca. 125 g
Mounting position Horizontal or vertical
Cooling The natural convection cooling must not be hin-
dered by cable ducts or other parts in the
switch-gear cabinet.
Electrical isolation Ethernet interface against the rest of the
module, each serial port against each other and
the rest of the module
Diagnosis
See Diagnosis
Ä
Chapter 1.7.6.4.7 “Diagnosis”
on page 1077
NOTICE!
Attention:
All I/O channels (digital and analog) are protected against reverse polarity,
reverse supply, short circuit and continuous overvoltage up to 30 VDC.
Multiple overloads
No effects of multiple overloads on isolated multi-channel modules occur, as
every channel is protected individually by an internal smart high-side switch.
Parameter Value
Bus connection 2 x RJ45
Switch Integrated
Technology Hilscher netX100
Transfer rate 10/100 Mbit/s (full-duplex)
Transfer method According to Ethernet II, IEE802.3
Communication Interface Modules (S500) > PROFINET
2019/04/173ADR010121, 13, en_US1082
