Table 196: Option Cover
Parameter Value
Weight 5 g
Dimensions 40 mm x 40 mm x 3 mm
Table 197: Terminal Block for Power Supply
Parameter Value
Type Screw clamp plug, wire connection from front
Usage For AC500-eCo processor modules
Conductor cross section
Solid 0.2 mm²...2.5 mm²
Flexible (with wire-end ferrule only) 0.2 mm²...2.5 mm²
Stripped conductor end 7 mm...8 mm
Fastening torque 0.5 Nm
Degree of protection IP20
Dimensions 25.4 mm x 17.4 mm x 15.1 mm
Weight 5 g
Table 198: Terminal Block for Serial RS-485 Adaptor
Parameter Value
Type Screw clamp plug, wire connection from side
Usage for
Ä
Chapter 1.8.1.4 “TA562-RS - Serial RS-485
Adaptor” on page 1112
Ä
Chapter 1.8.1.5 “TA569-RS-ISO - Serial
RS-485 Isolated Adaptor” on page 1113
Ä
Chapter 1.8.1.6 “TA562-RS-RTC - Adaptor
with Serial RS-485 (COM2) and Real-time
Clock ” on page 1114
Conductor cross section
Solid 0.14 mm²...1.5 mm²
Flexible (with wire-end ferrule only) 0.14 mm²...1.5 mm²
Stripped conductor end 7 mm
Fastening torque 0.4 Nm
Degree of protection IP20
Dimensions 19.05 mm x 8.7 mm x 19.1 mm
Weight 5 g
Part No. Description Product Life Cycle Phase *)
1TNE 968 901 R3203 TA570, spare part set for
AC500-eCo processor mod-
ules, 3x6 pieces
Active
Technical Data
Ordering Data
2019/04/173ADR010121, 13, en_US1122
