The TA563-TA565 terminal blocks are used to connect process signals and process voltages to
AC500-eCo I/O modules and AC500-eCo processor modules (with -P extension inside their
type designator only). 3 different kind of terminal blocks are available:
● Screw terminals with cable insertion on the side
● Screw terminals with cable insertion on the front
● Spring terminals with cable insertion on the front
Of each kind, 2 sizes are available:
● Terminals with 9 poles
● Terminals with 11 poles.
There are 2 compatible variants of each kind and size.
WARNING!
For screw terminals only: Danger of death by electric shock!
The IP 20 protection degree is only provided if all terminal screws are tightened.
Tighten all screws of unused load terminals of relay outputs if voltages > 24 V
are connected to the relay group.
Table 212: Screw-type Terminals (TA563/TA564)
Parameter Value
Type Front terminal or side terminal (depending on
model)
Conductor cross section
Solid
0.5 mm
2
to 2.5 mm
2
Flexible
0.5 mm
2
to 2.5 mm
2
Stripped conductor end
TA563 8 mm
TA564 10 mm
Width of the screwdriver 3.5 mm
Fastening torque 0.4 Nm - 0.5 Nm
Degree of protection IP 20 (if all terminal screws are tightened)
Conductor cross section flexible, with ferrule
with/without plastic sleeve
Min. 0.25 mm
2
Max. 1.5 mm
2
Table 213: Spring Terminals (TA565)
Parameter Value
Type Front terminal
Conductor cross section
Solid
0.5 mm
2
to 2.5 mm
2
Flexible
0.5 mm
2
to 2.5 mm
2
Stripped conductor end 10 mm
Degree of protection IP 20
Conductor cross section flexible, with ferrule
with/without plastic sleeve
Min. 0.25 mm
2
Max. 1.5 mm
2
Intended Pur-
pose
Technical Data
System Assembly, Construction and Connection
AC500-eCo > Handling of Accessories
2019/04/173ADR010121, 13, en_US1242
