ABB AC500 PLC - Page 265

10
11
NO8
NO9
13
NO11
12
NO10
14
NO12
15
NO13
16
NO14
17
NO15
18
R8..15
19
L+
20
M
24 V DC
-
+
1
2
NO0
NO1
4
NO3
3
NO2
5
NO4
6
NO5
7
NO6
8
NO7
9
R0..7
24 V DC
-
+
24 V DC
-
+
Fig. 16: Connection of 24 VDC actuators
Device Specifications
I/O Modules > Digital I/O Modules
2019/04/17 3ADR010121, 13, en_US 265
