ABB AC500 PLC - Page 33

Power supply 24 VDC 100 - 240 VAC
Max. power dissipation within
the processor module
PM554-TP: 3.0 W
PM554-TP-ETH: 3.3 W
PM554-RP: 3.5 W
PM556-TP-ETH: 3.3 W
PM564-TP: 3.9 W
PM564-TP-ETH: 4.4 W
PM564-RP: 4.5 W
PM564-RP-ETH: 4.9 W
PM566-TP-ETH: 4.4 W
PM554-RP-AC: 4.8 W
PM564-RP-AC: 4.8 W
PM564-RP-ETH-AC: 5.3 W
Processor module interfaces I/O bus, COM1, COM2 (optional), Ethernet (depending on
model)
Connection system see System Assembly, Construction and Connection
Ä Chapter 2.5 “AC500-eCo” on page 1192
Weight PM554-TP: 300 g
PM554-TP-ETH: 300 g
PM554-RP: 350 g
PM556-TP-ETH: 300 g
PM564-TP: 300 g
PM564-TP-ETH: 300 g
PM564-RP: 350 g
PM564-RP-ETH: 350 g
PM566-TP-ETH: 300 g
PM554-RP-AC: 400 g
PM564-RP-AC: 400 g
PM564-RP-ETH-AC: 400 g
Mounting position horizontal or vertical
*) These values show the value of the apparent current (sum of active and reactive current)
Program memory 128 kB Flash EPROM (PM554-xP and
PM564-xP types)
512 kB Flash EPROM (PM556-xP and
PM566-xP types)
Data memory
- VAR data 10 kB
- VAR_RETAIN data 1 kB, always buffered in flash
- %RB data (persistent) 1 kB, can be buffered in flash (depending on
configuration)
- %MB data 2 kB (PM554 and PM564 types)
64 kB (PM556 and PM566 types)
Data buffering In flash memory
Real time clock (RTC) Optional
Battery low indication Warning
Detailed Data
Device Specifications
Processor Modules > AC500-eCo
2019/04/17 3ADR010121, 13, en_US 33
