No. Name Value Internal
value
Internal
value,
type
Default Min. Max. EDS
Slot/
Index
9
to
14
Channel
configu-
ration
and
channel
moni-
toring of
the input
channels
1 to 3
see tables
"Channel configura-
tion" and "Channel
monitoring"
Byte
Byte
Default
0x00
0x00
0
0
19
3
0x0Y08
to
0x0Y0D
15 Channel
configu-
ration
Output
channel
0
see table
"Channel configura-
tion"
Byte Default
0x00
0 130 0x0Y0E
16 Channel
moni-
toring
Output
channel
0
see table
"Channel moni-
toring"
Byte Default
0x00
0 3 0x0Y0F
17 Substi-
tute
value
Output
channel
0
only
valid for
output
channel
0
0...0xffff Word Default
0x0000
0 65535 0x0Y10
18 to 21 Channel
configu-
ration
and
channel
moni-
toring of
the
output
channels
1 to 2
see tables
"Channel configura-
tion" and "Channel
monitoring"
Byte
Byte
Default
0x00
0x00
0
0
130
3
0x0Y11
to
0x0Y14
22 Channel
configu-
ration
Output
channel
3
see table
"Channel configura-
tion"
Byte Default
0x00
0 130 0x0Y15
23 Channel
moni-
toring
Output
channel
3
see table
"Channel moni-
toring"
Byte Default
0x00
0 3 0x0Y16
1
) With CS31 and addresses less than 70 and FBP, the value is increased by 1
2
) Not with FBP
Device Specifications
I/O Modules > Analog I/O Modules
