No. Name Value Internal
value
Internal
value,
type
Default Min. Max. EDS
Slot/
Index
6 Behav-
iour of
outputs
at com-
munica-
tion
errors
Off
Last
value
Substi-
tute
value
0
1+(n*5)
2+(n*5),
n £ 2
Byte Off
0x00
0 2 0x0Y05
7 Channel
configu-
ration
Input
channel
0
see table
Channel configura-
tion
Byte Default
0x00
0 19 0x0Y06
8 Channel
moni-
toring
Input
channel
0
see table
Channel monitoring
Byte Default
0x00
0 3 0x0Y07
9
to
22
Channel
configu-
ration
and
channel
moni-
toring of
the input
channels
1 to 7
see tables
channel configura-
tion and channel
monitoring
Byte
Byte
Default
0x00
0x00
0
0
19
3
0x0Y08
to
0x0Y15
23 Channel
configu-
ration
Output
channel
0
see table
Channel configura-
tion
Byte Default
0x00
0 130 0x0Y16
24 Channel
moni-
toring
Output
channel
0
see table
Channel monitoring
Byte Default
0x00
0 3 0x0Y17
25 Substi-
tute
value
Output
channel
0
only
valid for
output
channel
0
0...0xffff Word Default
0x0000
0 65535 0x0Y18
