No. Name Value Internal
value
Internal
value,
type
Default Min. Max. EDS
Slot/
Index
26 to 31 Channel
configu-
ration
and
channel
moni-
toring of
the
output
channels
1 to 3
see tables
channel configura-
tion and channel
monitoring
Byte
Byte
Default
0x00
0x00
0
0
130
3
0x0Y19
to
0x0Y1E
32 Channel
configu-
ration
Output
channel
4
see table
Channel configura-
tion
Byte Default
0x00
0 128 0x0Y1F
33 Channel
moni-
toring
Output
channel
4
see table
Channel monitoring
Byte Default
0x00
0 3 0x0Y20
34
to
39
Channel
configu-
ration
and
channel
moni-
toring of
the
output
channels
5 to 7
see tables
channel configura-
tion and channel
monitoring
Byte
Byte
Default
0x00
0x00
0
0
128
3
0x0Y21
to
0x0Y26
1
) With CS31 and addresses less than 70 and FBP, the value is increased by 1
2
) Not with FBP
GSD file:
Ext_User_Prm_Data_Len =
Ext_User_Prm_Data_Const(0) =
24
0x05, 0xe2, 0x15, \
0x01, 0x00, 0x00 \
0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
0x00, \
0x00, 0x00, 0x00, 0x00, \
0x00, 0x00, 0x00, 0x00, 0x00, 0x00;
