The 2 SGND signals are internally interconnected.
The assignment of the terminals:
Terminal Signal Description
1 C0..1 Input common for signals I0 and I1
2 I0 Input signal I0 (axis enable and limit
switch)
Function Modules > S500-eCo
2019/04/17 3ADR010121, 13, en_US 637
