Parameter Value
Pulse outputs Pulse specification
● 2 outputs for each axis, configurable
● Type: RS-422 differential signal
● Mode: CW & CCW or Pulse & Direction
● Frequency: 10 Hz to 250 kHz
● Pulse number: -2147483648 to
2147483647 (32 bits)
● Motion profiles generator
Output data lenth 32 bytes
LED displays For power supply, errors and signal states
Internal power supply Via I/O bus
External power supply Via the terminals ZP and UP (process voltage
24 VDC)
Process supply voltage UP Value
Connections Terminal 19 for UP (+24 VDC) and terminal 20
for ZP (0 V)
Rated value 24 VDC
Current consumption via UP terminal 42 mA
Max. ripple 5 %
Inrush current from UP (at power up) 0.067 A²s
Protection against reversed voltage Yes
Rated protection fuse for UP Not necessary
Current consumption from 24 VDC power
supply at the L+/UP and M/ZP terminals of the
CPU/bus module
Ca. 5 mA
Galvanic isolation Yes, between input groups and the output
group and the rest of the module
Isolated groups 5 groups (2 groups for 4 input channels, 1
group for 4 pulse train output channels, 1
group for process supply voltage, 1 group for
the rest of the module)
Surge-voltage (max.) 35 VDC for 0.5 s
Max. power dissipation within the module 1.2 W
Weight Ca. 125 g
Mounting position Horizontal or vertical
Cooling The natural convection cooling must not be
hindered by cable ducts or other parts in the
switch-gear cabinet.
No effects of multiple overloads on isolated multi-channel modules occur, as every channel is
protected individually by an external fuse.
No effects of
multiple over-
loads
Function Modules > S500-eCo
2019/04/17 3ADR010121, 13, en_US 649
